SF-19 Water Thermometer
PURPOSE
- Water temperature measurement at different depths in rivers, lakes, wells, holes, and other waters
COMPLETE SET
- Panel (with 1.5V АА batteries - 4 pcs.)
- Temperature probe
- Software
- RS232 cable
- Case
CERTIFICATES
- № 12324 State Committee for Standardization of the Republic of Belarus
SPECIFICATIONS
|
Water temperature range |
-5°С to +35°С |
|
Measurement accuracy |
± 0.1°С |
|
Sensor immersion range |
0 - 25 m |
|
Power source - internal |
4.5 - 6.6 V |
|
Current consumption |
≤ 250 mА |
|
Interface |
RS-232 |
|
Protection of the probe shell |
IP 68 |
|
Protection of the panel shell |
IP 40 |
|
Life time |
8 years |
|
Panel operation environment (ambient temperature) |
-25°С to +35°С |
|
Probe operation environment (hydrostatic pressure) |
0 - 2 500 gPa |
|
Panel overall dimensions (L × W × H) |
120×200×50 mm |
